Huatest is the major brands in Huatest marketing of generic electronic measurement instrumentation, its products have Digital Storage Oscilloscopes. Huatest Digital Storage Oscilloscope own core technology, national invention patents, with a trigger signal waveform to obtain accurate, reliable, stable performance, high sampling rates, but also lightweight, weighing 1.8 kilogram, size 153mm×320mm×98mm, easy to carry, elegant appearance, easy to operate.
Huatest Oscilloscope Technical Specification
|
Model |
HT100A∕HT100 |
HT60A∕HT60 |
HT40A∕HT40 |
HT25A∕HT25 |
|
Bandwidth |
100MHz |
60MHz |
40MHz |
25MHz |
|
Channels |
2 |
2 |
2 |
2 |
|
Realtime Sample Rate |
1.0GS/s |
1.0GS/s |
500MS/s |
250MS/s |
|
Rise Time |
＜3.5ns |
＜5.8ns |
＜8.8ns |
＜14ns |
|
Time Base Range |
5ns—50s/div |
5ns—50s/div |
10ns—50s/div |
25ns—50s/div |
|
Display |
Color / Monochrome |
Color / Monochrome |
Color / Monochrome |
Color / Monochrome |
|
Input Coupling |
DC、AD、GND |
|
Input Impedance |
1MΩ±2﹪，When 16pF±3pF |
|
Sensitivity |
2mV-5V/div |
|
Resolution |
8 bits |
|
Position Range |
2mV/div-200mV/div±2V
＞200mV/div-5V/div±50V |
|
Bandwidth Limit |
20MHz |
|
Trigger Sources |
CH1、CH2、Ext、Ext/5、AC Line |
|
Trigger Type |
Edge、Video、Pulse Width |
|
Record Length |
2048 points/channel |
|
Automatic Measurements |
Vavg、Vpp、Veff、Vmax、Vmin、Rise Time、Fall Time、
Positive Width、Negative Width、Closure、Frequency、Period |
|
Storage |
１０Waveforms、１０Setups |
|
LCD Type |
SNT / TFT LCD |
|
LCD Resolution |
320×240 |
|
Contrast Gradient |
Adjustable |
|
Brightness |
65cd/㎡ |
|
Supply Voltage |
AC220V±20﹪ 50Hz |
|
Power Dissipation |
＜30W |
|
Connection |
Color with USB Device |
|
Size |
153mm×320mm×98mm |
|
Weight |
Net Weight： 1.8 kg
Gross Weight：2.6 kg |
|
