Name:HT50A Oscilloscope

Details
HT50A Huatest Oscilloscope Technical Specification:
Model
HT50A
Bandwidth
50MHz
Channels
2
Realtime Sample Rate
500MS/s
Rise Time
<7.8ns
Time Base Range
10ns—50s/div
Display
Color
Input Coupling
DC, AD, GND
Input Impedance
1MΩ±2%, When 16pF±3pF
Sensitivity
2mV-5V/div
Resolution
8 bits
Bandwidth Limit
20MHz
Trigger Sources
CH1, CH2, Ext, Ext/5, AC Line
Trigger Type
Edge, Video, Pulse Width
Record Length
2048 points/channel
Automatic Measurements
Vavg, Vpp, Veff, Vmax, Vmin, Rise Time, Fall Time,
Positive Width, Negative Width, Closure, Frequency, Period
Storage
10 Waveforms, 10 Setups
Mathematic Functions
FFT, +, -, ×
LCD Type
TFT
LCD Resolution
320×240
Contrast Gradient
Adjustable
Brightness
65cd/m2
Supply Voltage
AC220V±20% 50Hz
Power Dissipation
<30W
Connection
USB
Size
153mm×320mm×98mm
Weight
Net Weight: 1.8 kg
Gross Weight: 2.6 kg
Oscilloscope HT50A
